Polyphenylene Sulfide (PPS) is an organic semi-crystalline polymer with high stable chemical bonds. PPS's outstanding chemical and temperature resistance distinguishes it from all other high-performance materials.
1. Exceptional chemical resistance , there is no known solvent capable of disolcing PPS at temperature below 200C / 400F
2. With a continous use temperature of 190C/380F, PPS performs well in high temperature environments without degradation of its properties.
3. High dimensional stability providing low creep under a wide range of loading conditions.
4. Low moisture absorption and high resistance to hydrolysis
5. An inherently flame retardant material PPS offers higher consistecy and durability in fibers
6. Easly meets most industry requirements including the FAA low Flame, Low smoke and toxicity rating
Features:
The maximum allowable working temperature is high in the air (can work at 240 ºC for the short time of up to 260 ºC):
(1)high mechanical strength,
(2)stiffness and hardness
(3)excellent resistance to chemical corrosion and the hydrolysis performance.
(4)excellent wear resistance and frictional resistance
(5)good dimensional stability
(6)good resistance to high energy radiation
(7)good ultraviolet resistance,
(8)itself has the flame retardancy, excellent electrical insulation
PPS (Polyphenylene Sulfide) Monofilament Product Specification Series
PPS (Polyphenylene Sulfide) | Nominal Diameter (mm) | Diameter Tolerance (mm) | Breaking Tenacity (N) | Elongation at Break (%) | Heat Shrinkage Rate (200°C, 30min) % |
Ultra-fine Monofilament Series | 0.05 | ±0.005 | ≥ 1.2 | 15 - 30 | 1--7 |
0.08 | ±0.005 | ≥ 2.8 | 18 - 35 | 1--7 | |
0.1 | ±0.008 | ≥ 4.5 | 18 - 40 | 1--7 | |
Regular Fine Monofilament Series | 0.12 | ±0.010 | ≥ 6.5 | 18 - 40 | 1--7 |
0.15 | ±0.010 | ≥ 10.0 | 18 - 42 | 1--7 | |
0.2 | ±0.012 | ≥ 18.0 | 18 - 45 | 1--7 | |
0.25 | ±0.012 | ≥ 28.0 | 18 - 45 | 1--7 | |
0.3 | ±0.015 | ≥ 35.0 | 18 - 45 | 1--7 | |
Coarse/Heavy-duty Monofilament Series | 0.35 | ±0.015 | ≥ 40.0 | 18 - 45 | 1--7 |
0.4 | ±0.018 | ≥ 72.0 | 18 - 45 | 1--7 | |
0.5 | ±0.020 | ≥ 112.0 | 18 - 45 | 1--7 | |
0.6 | ±0.022 | ≥ 160.0 | 18 - 45 | 1--7 | |
0.8 | ±0.025 | ≥ 285.0 | 18 - 45 | 1--7 |
Application Positioning：
1.Ultra-fine Monofilament Series
High-precision filtration, special woven fabrics (such as ultra-fine screen mesh), high-performance composite material reinforcement, special textiles.
2.Regular Fine Monofilament Series
Industrial filter cloth, paper forming wire/dryer fabric, power plant filter bags, base fabric for sealing materials (core specifications).
3.Coarse/Heavy-duty Monofilament Series
Heavy-duty filter cloth, wear-resistant conveyor belts, special ropes, brushes, chemical packing supports.
